GM300 Series ST 3-Axis Probe
$550.00
Three-axis vector probe for the GM330 magnetometer—three X, Y, Z sensors read all field components at once and report true magnitude regardless of orientation, plus a configurable button for Freeze, Data Collection, Peak Hold, and Autozero.
Choose it when the field direction is unknown, changing, or awkward to chase by hand—no aligning the probe to get an accurate reading.
Description
Three-Axis Vector Probe for the GM330 Magnetometer
This probe houses three single-axis sensors oriented along the X, Y, and Z axes, so it reads all three components of the magnetic field at once. The meter reports each axis individually along with the total magnitude—the true field strength regardless of how the probe is held.
That’s the point of a three-axis probe: with a single-axis probe you have to align the sensor to the field to read it accurately, and a misaligned probe under-reads. A three-axis probe removes that step. Position it anywhere in the field and the magnitude is correct, which makes it the right tool when the field direction is unknown, changing, or simply awkward to chase by hand.
Every GM300 Series probe includes a configurable button that puts common functions at your fingertips. From the meter, you can assign it to Freeze Reading, Start/Stop Data Collection, Peak Hold Reset, or Autozero—so you can trigger the action you use most without reaching back to the instrument.
Probe Type: 3-Axis
Sensitivity range: 0.1 Gauss – 30 kGauss (ST Type)
